New generation of Vertical turning lathes 8. 3. 2022
Vertical turning lathe design with carousel table according to customer‘s request. Table load capacity according to the clamping plate size is 70 - 320 tons. Fixed columns with a vertically movable cross rail are connected with a fixed cross beam that reinforces the whole frame of machine. The result is a very high rigidity and accuracy of the complete machine.
Vertical turning lathe of Gantry type design equipped with carousel table. The machine travel is 1m extended for the automatic pick up of turning and milling heads at the end of the workplace.
Sliding columns with a vertically movable cross rail are connected with a fixed beam, that reinforces the whole frame of the machine.
Both variants of vertical turning lathe can be equipped with two variants of headstocks TURN design suits only for turning operations. COMBI design offers turning and milling operations. It uses Direct Drive to achieve high working milling operations. A headstock with an extensible ram is movable along the cross rail in the transverse direction. All axes are fully hydrostatic, guideways are covered by telescopic covers. The machine can be equiped with a set of milling and turning heads to widen the machining possibilities of the machine. In the basic version, the heads are placed in pallets and equipped with automatic clamping on the ram face. Standard heads are facing and angular, optional NC controlled. Special milling heads can be added upon the request or for special technological operations. The workstation also includes automatic tool changer - optional robotic tool changer with various magazine size. Tool cooling is external and through tool.
